Filtration
1 Filtration modes.
2 Manual: Allows the ltration process to be turned on
and off manually.
3 Filter cleaning: This mode is used to backwash the
lter.
4 Automatic: In this mode, ltration is turned on
according to the start and end times set in the time
slots. The time slots always operate on a daily basis.
5 Smart*: This mode is based on the automatic mode,
with its three ltration intervals, but the ltration times
are adjusted according to the temperature. This is
done by setting two temperature parameters: the
maximum temperature, above which the ltration
times will be determined by the time slots, and the
minimum temperature, below which ltration will be
reduced to ve minutes, the minimum operation period.
Between these two temperatures, the ltration times
will be staggered linearly. The antifreeze mode can be
activated to turn the ltration on if the water temperature
falls below 2°C.
6 Heating : This mode acts in the same way as the
automatic mode, but it can also operate via a relay that
controls the temperature. The set point temperature is
determined in this menu and the system operates with
a hysteresis of one degree (for example: if the set point
temperature is 23°C, the system will start up when the
temperature falls below 22°C and shut down only when
it rises above 23°C).
Heating control OFF: The heating operates only during
the ltration periods congured.
Heating control ON: Keeps the ltration on after
the ltration period has expired if the temperature is
below the set point temperature. When the setpoint
temperature is reached, the ltration and heating stop
and only resume when the next programming period
begins.
7 Intelligent*: In this mode, the user has two operating
parameters: Select the required water temperature
and the minimum ltration time (minimum two hours
and maximum 24 hours). The ltration will operate
for at least ten minutes every two hours to check the
temperature. The minimum ltration time selected is
divided into twelve sections that are added to its ten
minutes. Example 1: Over twelve hours, the time
is divided between the twelve times a day when the
ltration starts up to check the temperature.
Example 2: (12 hours x 60 minutes) / 12 = 60 minutes
every two hours. This is the ltration and heating
period every two hours. If the programmed ltration
period ends and the required temperature has not
been reached, the ltration and heating remain on until
the required temperature is reached. To minimize the
number of hours during which ltration operates each
day, this additional time will be deducted from the next
ltration periods occurring during the rest of the day.
(See the chart below).
0h
10 min
1h 3h 5h 7h 9h 11h 13h 15h 17h 19h 21h 23h
2h 4h 6h 8h 10h 12h 14h 16h 18h 20h 22h 24h
T°= 28ºC
0h
10 min
1h
OFF
ON
3h 5h 7h 9h 11h 13h 15h 17h 19h 21h 23h
2h 4h 6h 8h 10h 12h 14h 16h 18h 20h 22h 24h
28ºC 28ºC
27ºC 27ºC
28ºC
Intelligent mode operation if the temperature is constant
Intelligent mode operation if the temperature varies
Intelligent mode
1 2 3 4
OK
+
7
5 6
-
+
-
+
-
+
-
