Operating status:
LED
colour
Status Meaning
Measuring mode Bus mode
Green Steady
light
Ready to take measurements CAN Operational (PDO transfer
possible)
Green Flashing Data is transferred via the
interface
-
Yellow Steady
light
Ready to take measurements CAN-bus Pre-operational (no PDO
transfer possible)
LED
colour
Status Meaning Remedy
Measuring mode Bus mode
Red Flashing Measured value
overflow
LCD error
CAN transmission
error
Adapt measuring range
Restart
Red Steady
light
Initialisation phase:
not ready to take
measurements yet,
calibration error
Original calibration
error
CAN-bus not ready for
communication (bus
OFF)
Please wait
Send PME to
manufacturer (HBM)
