Modules and transducers
110 I3031-14.0 HBM: public Quantum
X
Orange Connection newly assigned, transducer identification running
(calibration)
Green Error-free operation
Flashing green (5s),
then green
TEDS data being read in
Flashing orange (5 s),
then green
Manual configuration ongoing (ignore TEDS)
Red No sensor connected
Channel error (incorrectly parameterized, connection error,
invalid TEDS data)
CAN LEDs
Green CAN bus activated, CAN data can be received
Orange CAN bus in "WARNING" state, CAN data received but bus is
subject to occasional disruptions; buffer overflow, some data
items lost
Red CAN bus in "ERROR" or "BUS-OFF" state, CAN data cannot
be received or processed
General rule: Brief flashing TEDS identified (green: is used,
orange: is not used).
8.6 MX238B Strain gage fullbridge
measuring amplifier
You can connect up to four transducers to the universal
amplifier MX238B. The transducers are connected via
15-pin D-SUB-15HD device connectors. All measuring
channels are electrically isolated from one another and
from the power supply.
