HBM MX1601B - 9.6 Quarter Bridge, SG Connection

Transducer connection
Quantum
X
I3031-14.0 HBM: public 143
9.6 Quarter bridge, SG
Amplifier with direct support of SG quarter bridges:
MX1615B.
Quarter bridges can be connected via an adapter to:
MX840B, MX440B, MX430B and MX410B. For connect
ing individual SGs to this adapter see the following page.
Hsg. = Housing
2 Data
3 No function
1
4
7
1
123
1-wire EEPROM (optional)
view from below
Four-wire circuitThree-wire connection
8
Cable shield
5
6
SG
SG
bk
gy
gn
ye
bu
MX1615B
1
8
Push in
Cable color code:
wh= white;
bk= black;
bu= blue; rd= red;
ye = yellow;
gn= green;
gy= gray
