HBM MX1601B - 9.26 Rotary Encoder and Pulse Generator

Transducer connection
166 I3031-14.0 HBM: public Quantum
X
9.26 Rotary encoder and pulse generator,
single pole with static directional
signal
Supported by the following modules: MX840B, MX440B,
MX460B
6
10
8
3
Industrial
pulse gen
eratos
f
2
(+)
Zeroing pulse +
9
4
7
2
5
5 V
3,5 V
1,5 V
Impulse
Left
f
1
0 V
f
1
(+)
Hsg.
Cable shield
1
5
6
10
11
15
Direction
Clockwise
f
2
Not included in TEDS standard
Maximum input voltage: 5 V to ground
NOTE
Signal single-pole, schematic diagram
Adjustable sensor supply: Pin12: 5 V ... 24 V
Pin 11: 0 V
Hsg. = Housing
