HBM MX1601B - PWM - Pulse Width, Pulse Duration, Period Duration, Single-Pole

Transducer connection
172 I3031-14.0 HBM: public Quantum
X
9.31 PWM - Pulse width, pulse duration,
period duration, single-pole
Supported by the following modules: MX460B
6
10
9
4
7
2
5
f
1
(+)
Hsg.
Cable shield
Hsg. = housing
1
5
6
10
11
15
6
1
123
2 Data
3 No function
1
Adjustable sensor supply: Pin12: 5 V ... 24 V
Pin 11: 0 V
Transducer
