10 Functions and outputs
The MX410B, MX430B, MX460B as well as MX878B,
MX879B modules can perform calculations in real time,
with the results available as standard system signals.
These system signals can be used like actual measure
ment signals for subsequent tasks (analog output, Ether
CAT® signal, source signal for mathematics function,
data visualization and storage).
The MX878B, MX879B MX410B and MX430B modules
feature analog outputs that can be connected to a sys
tem or source signal, for example an actual measure
ment signal (additionally scaled, filtered) or the result of a
mathematics function. MX879B bietet zudem digitale
Ein- und Ausgänge (binär, statisch). Die digitalen Ein
gänge werden zeit-gestempelt. Einige digitale Ausgänge
können in Echtzeit mittels Limit-Switch aktiviert werden.
Measurement channels that are used in mathematics
functions or directly for analog outputs need to be acti
vated for “isochronous data transfer” (for example in the
QuantumX Assistant software, ”Signals” tab).
Notice
The module configuration is immediately active after sys
tem reboot (Auto Startup). No operating PC is required
for configured signal outputs to run standalone.
