HBM MX1601B - Amplifier Analog Outputs and Realtime Functions

Functions and outputs
176 I3031-14.0 HBM: public Quantum
X
Realtime functions overview
Module Peak
values
Add
and
multiply
Root
Mean
Square
(RMS)
Rotation
and
angular
differ
ence
PID
con
troler
Mat
rix
Signal
gener
ator
Limit
value
switch
MX410B x x
MX403B x x
MX430B x
MX460B x x
MX878B x x x x x x
MX879B x x x x x x x
10.1 Amplifier with analog outputs
Module wie z.B. MX410B oder MX430B bieten je einen
Analogausgang pro Messkanal, der über BNC‐Buchse an
der Frontseite abgreifbar ist.
The outputs are directly assigned to the inputs located
above them.
Fig. 10.1 MX410B front view
