Connecting individual QuantumX modules
84 I3031-14.0 HBM: public Quantum
X
Connection to Port 3 - Port 4: 1 hop
Connection to Port 1 and/or 2 - Port 4: 2 hops
Port1
Phy 1
Port 1 Port 2 Port 3
Port 4
Port2 Port3
Port4
Phy 2
Fig. 7.14 Connection situation on the AVT 1394b hub
Notice
Always connect the chain with the most modules to Port
3 or Port 4.
