Modules and transducers
90 I3031-14.0 HBM: public Quantum
X
11
12
Hsg.
9
Supply voltage 5V … 24V
1)
Power supply 0V
4
1)
Adjustable via software
Cable shield
Sensor
Connection as per measurement
principle
Hsg. = Housing
CAUTION
Check the correct voltage setting when connecting a
sensor. Too high a voltage can destroy the sensor. The
sensor supply is switched off in condition at the time of
delivery.
