1 Introduction
10 A04089_07_E00_02 HBM: public MX Modules
n
CX22B-R Data Recorder: The CX22B-R is shipped with the pre-installed
catman EasyDAQ software package for test parameterization, visualization and
data analysis in the field. The acquired test data is stored on the integrated SSD
memory.
NOTE
Details about the CX22B-R can be found in the separate CX22B-R user manual.
n
CX27C-R Industrial Ethernet Gateway: The module is used for the integration
of SomatXR modules into fieldbusses like EtherCAT® or PROFINET. The
module can also be used as gateway to connect multiple SomatXR modules
connected via FireWire and to a PC via Ethernet.
NOTE
Details about the CX27C-R can be found in the separate CX27C-R user manual.
n
EX23-R PoE Ethernet Switch: The EX23-R is a ruggedized 10-port Gigabit
switch that supports IEEE1588 PTPv2 transparent clock time synchronization.
Five ports provide Power over Ethernet (PoE) to support cameras and other low
power Ethernet based data sources.
NOTE
Details about the EX23-R can be found in the separate CX23-R and EX23-R user
manual.
