HBM MX840B-R - CAN Devices

5 Inputs
MX Modules A04089_07_E00_02 HBM: public 93
5.13 CAN devices
Transducer MX840B-R MX471B-R MX471C-R
CAN bus
database or raw message
●
connector 1
●
§
database only
●
§
database only
CAN FD bus
●
§
Including support for CCP/XCP-on-CAN (not in combination with CX23-R).
NOTE
To ensure normal operation, the CAN bus needs to be terminated at both ends
using appropriate termination resistors. The MX471B-R, MX471C-R and
MX840B-R provide internal completion resistors between CAN H and CAN L that
can be enabled or disabled individually with software.
