1 Introduction
1.1 SomatXR DAQ
The SomatXR Rugged DAQ series is a modular and universally applicable
measurement system. The modules of this family can be individually combined and
intelligently connected according to the measurement task. The distributed operation
makes it possible to position individual modules close to the measuring points,
resulting in short sensor lines.
The SomatXR Rugged DAQ series consists of the following modules:
n MX840B-R universal module: Up to eight (8) universal inputs for connecting
more than 16 transducer technologies including one connector compatible with
CAN inputs.
n MX1615B-R bridge module (strain gage amplifier): Up to 16 individually
configurable inputs, including strain gage-based transducers, standardized
voltage and resistance or resistance-based measurements.
n MX1601B-R standard module (universal amplifier): Up to 16 configurable inputs
for DC voltage sources (60 V, 10 V, 100 mV), DC current sources (20 mA) or
current-fed piezoelectric transducers (IEPE, ICP®).
n MX1609KB-R Thermocouple Amplifier , MX1609TB-R Thermocouple Amplifier:
Up to 16 thermocouples type K (Ni-CrNi) or respectively 16 thermocouple type T
(Cu-CuNi), can be connected to the respective modules for measuring
temperatures.
n MX411B-R highly dynamic universal module: Up to four (4) inputs, including
strain gage and inductive bridges, standardized voltage and DC current sources
(20 mA) or current-fed piezoelectric (IEPE, ICP®) and piezoresistive
transducers.
n MX460B-R frequency / counter module: Up to four (4) digital inputs to measure
digital pulses up to 1 MHz (speed, torque, angle position, displacement, PWM in
general).
n MX471B-R CAN module: Up to four (4) independent CAN bus nodes electrically
isolated from each other and from the power supply.
n MX471C-R CAN / CAN FD Module : Up to four (4) independent CAN / CAN FD
bus nodes electrically isolated from each other and from the power supply. The
module can also be used as a gateway to connect to multiple SomatXR modules
via FireWire and to a PC via Ethernet.
n MX590B-R pressure acquisition module: Configurable with up to five (5)
individual pressure transducers. Pressure measurement: absolute, up to 10 bar;
relative, up to 25 bar.
