HBM MX840B-R - Mechanical Fixing of Modules

2 Setting up a system
16 A04089_07_E00_02 HBM: public MX Modules
FireWire. For more information on module networking, see Connecting multiple
modules to a host PC and Module synchronization.
Finally, connect the desired sensors. For guidelines on connecting transducers, see
Connecting transducers.
2.2 Mechanical fixing of modules
See www.hbm.com for information about devices available for mounting SomatXR
rugged modules and accessories.
Order No. Item Description
1-CASELINK Installation parts Four (4) elements for
mechanical connection
1-CASELINK-
RUG-2
Caselinks Four (4) rugged elements for
mechanical connection
1-CASEMOUNT Mounting brackets Two (2) fixing brackets for
one (1) module, includes 1-
CASELINK
1-CASEMOUNT2-
2
Mounting brackets Two (2) fixing brackets for
two (2) modules, includes 1-
CASELINK-RUG-2
1-CASEMOUNT3-
2
Mounting brackets Two (2) fixing brackets for
three (3) modules, includes 1-
CASELINK-RUG-2
1-CASEMOUNT-
UMB-2
Universal mounting
bracket
SomatXR top mount bracket
for GPS, UPS, wireless
access points, cameras, etc.
