MX Modules A04089_07_E00_02 HBM: public 63
are: Walther-praezision, type LP-004. The HBM couplings 1-CON-S3006T
(aluminum, FKM sealing) and 1-CON-S3007T (stainless steel, FFKM sealing) are
equipped with a RFID-chip for the TEDS dataset. After attaching a coupling, the
content of the TEDS chip is read (RFID technology).
Pressure couplings (sold separately)
Order
Number
Description Material Sealing
Nominal
Pressure
range
Connection TEDS
1-CON-
S3006T
Pressure
coupling
Aluminum FKM < 10 bar M12 x 1.5 (external
thread)
via
RFID
1-CON-
S3007T
Pressure
coupling
Stainless
steel
FFKM ≥ 10 bar M12 x 1.5 (external
thread)
via
RFID
Programming TEDS
The couplings are delivered with an empty TEDS chip and must be programmed by
the user. To program the TEDS chip, make sure you have installed the TEDS Editor
(see the QuantumX System CD, setups\obsolete\TEDS_Setup.exe)
1. Run MX Assistant.
2. Search for the MX590B-R and connect to the module.
3. Make sure you have selected "use TEDS if available" in the Channel-Tab for
the channel you will program the TEDS chip on.
4. Connect the coupling to the corresponding channel. The Channel LED will
flash.
5. Select "open TEDS in HBM TEDS Editor" from the TEDS context-menu.
6. Once the TEDS chip content is available to the TEDS Editor, set "Maximum
pressure", "Pressure type" and "Channel name" to your desired values.
7. Click on "save TEDS and activate" and close the TEDS Editor.
