52 CD 2301 Order No. BA 92-12-0231A Issue 05.01.10
Changing the electronic board
Changing the electronic board may only be carried out by
sufficiently qualified personnel or by your service technician.
Before starting any repair or maintenance operation, always switch
the power unit off and disconnect the primary plug.
Do not wear a wrist watch or any electrically conductive jewellery.
To change the electronic board, proceed as described in
section 7.1 (Safety Instructions), 7.3 (Tools to be Used) and
7.4 (Open the Power Unit).
Replacement of the electronic board 80-80-5034
Loosen the plugs X1, X2, X3, and SV2.
8 Appendix
8.2 Spare Parts
