30
MPC Platinum Installation and Operation Manual
HT# 059085-00 F
Monday through Thursday: Vari-Boost begins before 6 am and ends at 6 am
Day temperature level is maintained from 6 am until before 10 PM
Early Shutdown starts before 10 PM and ends at 10 PM
Night temperature level is maintained from 10 PM.
Friday: Vari Boost begins before 7 am and ends at 7 am
Day temperature level is maintained from 7 am to 11 am
Night temperature level is maintained from 11 am to 1 PM
Day temperature level is maintained from 1 PM to 4 PM
Night temperature level is maintained from 4 PM to 6 PM
Day temperature level is maintained from 6 PM until before 10 PM
Early Shutdown starts before 10 PM and ends at 10 PM
Night temperature level is maintained from 10 PM.
Saturday: No Vari Boost because the Day#1 is not programmed
Day temperature level is maintained from 8 am until before 4 PM
Early Shutdown starts before 4 PM and ends at 4 PM
Night temperature level is maintained from 4 PM.
Sunday: Night temperature level is carried over from Saturday and maintained all day Sunday, ending at the
Vari Boost Monday morning
ALERT
On an Internet control with Space Average, the Boost can extend to an
additional hour if Day Target is not reached within the Boost period.
COPY SCHEDULE
SELECT: Settings/Schedules/Copy Schedule
• To reduce the need for setting each day's time schedule, this feature has been made to allow
the copying of Monday schedule to the rest of the week.
------ SCHEDULES ------
Copy Mon Schedules
To All Other Days
(Select to Execute)
VACATION SCHEDULE SETTING
(Used on Internet Communication Controls Only)
• The vacation Space Target and settings can only be set on the Internet ICMS website
(http://www.htcontrols.com).
• The MPC Platinum offers a Vacation Schedule with an adjustable lower space target that it
• During that time, the MPC Platinum uses the Vacation Schedule Space Target. However, it
also uses the Night Heat Adjustment and Night Outdoor Cutoff settings.
AUX RELAY SCHEDULE
Close/Open Schedules Mon #1 - 4 Default: Empty
SELECT: Settings/Schedules/Aux Schedule
• The Auxiliary (Aux) Clock is an extra Normally Open relay output that energizes based
only on the Aux Schedule. See "Wiring to Auxiliary Clock" on page 11.
• The relay status is programmable with a Close Time (Aux Clock relay is energized) and
an Open Time (Aux Clock relay is de-energized). There are four Close/Open Time pairs
available for each day of the week.
• The Aux Clock relay is not affected by outdoor temperature, but acts as a separate time
clock to turn on lights, fans, dampers, or other equipment.
• The Aux Clock has a separate schedule program from the Day/Night Schedule, but the times
are set in the same way. It is important to note that the Copy Schedule function does not
affect the Aux Schedule. Each day must be programmed individually.
-AUX RELAY SCHEDULE-
MON # 1
Close Time **:**
Open Time **:**
To Next Page
