MPC Platinum Installation and Operation Manual
HT# 059085-00 F
BACNET PICS STATEMENT
Product Model Number Protocol Revision Software Version Firmware Version
Platinum series BACnet Controls Varies 1.5 tbd tbd
Vendor Vendor ID Address and Phone
Heat-Timer Corporation 248 20 New Dutch Ln. Faireld, NJ 07004 - (973)575-4004
Product Description
MPC Platinum control for hot water heating applications. (see http://www.heat-timer.com for more information)

Product 
Platinum series BACnet Controls BACnet Application Specic Controller (B-ASC)
Supported BIBBs (Annex K)
Supported BIBBs BIBB Name
DS-RP-B Data Sharing-ReadProperty-B
DS-WP-B Data Sharing-WriteProperty-B
DM-DDB-B Device Management-Dynamic Device Binding-B
DM-DOB-B Device Management-Dynamic Object Binding-B
DM-DCC-B Device Management-DeviceCommunicationControl-B
Standard Object Types Supported
Object Type Creatable Deletable
Analog Value No No
Binary Value No No
Multi-State Value No No
Device No No
Data Link Layer Options (Annex J)
Product Data Link Options
Platinum series BACnet Controls BACnet/IP
Segmentation Capability
Segmentation Type Supported Window Size (MS/TP product limited to 1)
Able to transmit segmented messages No
Able to receive segmented messages No
Device Address Binding
Product Static Binding Supported
Platinum series BACnet Controls No
Character Sets
Product Character Sets supported
Platinum series BACnet Controls ANSI X3.4

heat-timer MPC Platinum Specifications

Power

voltage input	120 VAC 60 Hz
power consumption	30 VA Max/30 Amp Max
output relay ratings	1 Amp inductive, 6Amp resistive at 120 VAC 60 Hz, 15A total for all circuits

Temperature Control

temperature display	Fahrenheit or Celsius
sensor ranges	-35°F/-37°C to 250°F/121°C
system set point	70°F/21°C to 250°F/121°C

Weight and Dimensions

dimensions	5-1/8” x 13" x 13"
weight	14 pounds
