heat-timer MPC Platinum User Manual

38
MPC Platinum Installation and Operation Manual
HT# 059085-00 F
MS/TP ADDRESS/ MAC ADDRESS
• This is the MSTP MAC address on a RS485 network. Its MSTP range is 1 though 127. It is a
unique address within the network.
• The MS/TP address must be provided by the Network Administrator.
--MAC ADDRESS--
1
[
]
MSTP BAUD RATE
Options: 9600, 19200, 38400 Default: 9600
• The Baud determines the speed of communication.
• Both the Platinum control and BMS must use the same Baud rate.
• The communication is xed to 8 Data Bits, No Parity, and 2 Stop Bits.
--NETWORK SETTINGS-
BACnet ID: 1
1
9600
MS/TP Address:
Baud:
Switch to IP
MPC PLATINUM BACNET VARIABLE LIST
MPC
Platinum
OBJ ID
NAME TYPE

UOM
READ
ONLY
0 BOOSTADJ
DESCRIPTION
Vari-Boost Adjustment AV none (95)
RANGE / STATES /
SPECIAL VALUES
0.1 - 6.4
100 BOOSTMODE Boost Mode MV
1=BoostOff, 2=ManualBoost,
3=VariDay, 4=VariDayNight
200 BOOSTTIME Manual Boost Time AV Minutes(72) 0 - 120
300 BPTIME Bypass Time AV Minutes(72) 0 - 2,147,483,647 X
400 BYPASSMODE Bypass Mode BV 0=AUTO, 1=ON
500 CLENGTH Cycle Length AV Minutes(72) 10 - 240
600 DADJUST Day Heat Adjustment MV
1=A, 2=B, 3=C, 4=D, 5=E, 6=F,
7=G, 8=H, 9=I, 10=J, 11=K,
12=L,13=M, 14=N, 15=O, 16=P
700 DCUTOFF Outdoor Day Cutoff AV °C(62), °F(64) -6 - 38°C, 20 - 100°F
800 DLS Day Light Saving BV 0=Enable, 1=Disable
900 FAULTMODE Sensor Fault Mode BV 0=OutputOn, 1=OutputOff
1000 HDIFF System Differential AV °C(62), °F(64) 2 - 42°C, 3 - 75°F
1100 INMODE Sensor Mode BV 0=°F, 1=°C
1200 NADJUST Night Heat Adjustment MV
1=A, 2=B, 3=C, 4=D, 5=E, 6=F,
7=G, 8=H, 9=I, 10=J, 11=K,
12=L,13=M, 14=N, 15=O, 16=P
1300 NCUTOFF Outdoor Night Cutoff AV °C(62), °F(64) -6 - 38°C, 20 - 100°F
1400 ODTEMP Outdoor Sensor AV °C(62), °F(64) -40 - +122°C, -40 - +250°F X
1500 ODTRIM Outdoor Sensor Trim AV °C(62), °F(64) -3 - +3°C, -5 - +5°F
1600 OPMODE Operation Mode BV
0=Burner/valve, 1=District
Steam
1700 OUTPUT Output Relay BV 0=Off, 1=On X
1800 PDATE Panel Date AV
Days (70)
since 1/1/1981
0 - 2,147,483,647
1900 PTIME Panel Time AV
Minutes(72)
since 0:00
0 - 1439
2000
through
2055
SCHEDULES00
through
SCHEDULES55
Schedules AV
Minutes(72)
since 0:00
0 - 1439, 1440=empty schedule
2100 SEASON Season BV 0=Winter, 1=Summer
2200 SHIFT Day/Night Shift MV
1=To-Day, 2=To-Night,
3=Extend-Day, 4=To-Schedule
2300 SRUNON System Run-on AV Minutes(72) 0 - 60
2400 SYSSEN System Sensor AV °C(62), °F(64) -40 - +122°C, -40 - +250°F X
2500 SYSTEM System Relay BV 0=Off, 1=On X
2600 SYTRIM System Sensor Trim AV °C(62), °F(64) -3 - +3°C, -5 - +5°F

heat-timer MPC Platinum Specifications

Power

voltage input	120 VAC 60 Hz
power consumption	30 VA Max/30 Amp Max
output relay ratings	1 Amp inductive, 6Amp resistive at 120 VAC 60 Hz, 15A total for all circuits

Temperature Control

temperature display	Fahrenheit or Celsius
sensor ranges	-35°F/-37°C to 250°F/121°C
system set point	70°F/21°C to 250°F/121°C

Weight and Dimensions

dimensions	5-1/8” x 13" x 13"
weight	14 pounds
