Operating the Touchscreen | Gestures

132

HEIDENHAIN | TNC 620 | Conversational Programming User's Manual | 10/2017

Symbol Gesture Function

Two-finger drag Move a graphic or 3-D model

Spread Enlarge a graphic or 3-D model

Pinch Reduce a graphic or 3-D model

Selecting a contour

The control supports the following gestures:

Symbol Gesture Function

Tap on an element Select element

Tap on an element in the list-

view window

Select or deselect an element

Activate Add and tap on an

element

Part, shorten, or lengthen and element
