Operating the Touchscreen | Gestures

HEIDENHAIN | TNC 620 | Conversational Programming User's Manual | 10/2017

133

Symbol Gesture Function

Activate Remove and tap on an

element

Deselect an element

Double-tap on the background Reset the graphic to its original size

Swipe over an element Show a preview of selected elements

Show element information

Two-finger drag Move graphics

Spread Magnify the graphic

Pinch Reduce the graphic
