Parameter settings
DisplaySettings
Settings for the position display
Position display
with TOOL CALL DL
As Tool Length: The programmed oversize DL is considered as the tool length
modification for display of the workpiece-based position
As Workpiece Oversize: The programmed oversize DL is considered as the workpiece
oversize for display of the workpiece-based position
DisplaySettings
Settings for the table editor
Behavior when deleting tools from the pocket table
DISABLED: Deletion of the tool is not possible
WITH_WARNING: Deletion of the tool is possible, must be confirmed
WITHOUT_WARNING: Deletion of the tool is possible without needing to be confirmation
Behavior when deleting index entries of a tool
ALWAYS_ALLOWED: Deletion of index entries is always possible
TOOL_RULES: The behavior depends on the setting of the parameter "Behavior when
deleting tools from the pocket table"
Show the RÜCKS. SPALTE T soft key
TRUE: The soft key is shown and all tools can be deleted from the tool memory by the user
FALSE: The soft key is not shown
DisplaySettings
Setting the coordinate systems for the display
Coordinate system for the datum shift
WorkplaneSystem: Datum is displayed in the system of the tilted plane, WPL-CS
WorkpieceSystem: Datum is displayed in the workpiece coordinate system, W-CS
