Tables and Overviews | Machine-specific user parameters
20
HEIDENHAIN | TNC 620 | Conversational Programming User's Manual | 10/2017
783
Parameter settings
ProbeSettings
Configuration of tool measurement
TT140_1
M function for spindle orientation
-1: Spindle orientation directly by NC
0: Function inactive
1 to 999: Number of M function for spindle orientation
Probing routine
MultiDirections: Probing from several directions
SingleDirection: Probing from one direction
Probing direction for tool radius measurement
X_Positive, Y_Positive, X_Negative, Y_Negative, Z_Positive, Z_Negative
(depending on tool axis)
Distance between lower surface of tool and upper surface of stylus
0.001 to 99.9999 [mm]: Offset between stylus to tool
Rapid traverse in probing cycle
10 to 300 000 [mm/min]: Rapid traverse in probing cycle
Probing feed rate with tool measurement
1 to 3 000 [mm/min]: Probing feed rate with tool measurement
Calculation of probing feed rate
ConstantTolerance: Calculation of probing feed rate with constant tolerance
VariableTolerance: Calculation of probing feed rate with variable tolerance
ConstantFeed: Constant probing feed rate
Type of speed detection
Automatic: Determine speed automatically
MinSpindleSpeed: Use minimum spindle speed
Maximum permissible rotational speed the tool tip
1 to 129 [m/min]: Permissible rotational speed on cutter circumference
Maximum permissible speed with tool measurement
0 to 1 000 [rpm]: Maximum permissible speed
Maximum permissible measuring error with tool measurement
0.001 to 0.999 [mm]: First maximum permissible measuring error
Maximum permissible measuring error with tool measurement
0.001 to 0.999 [mm]: Second maximum permissible measuring error
NC stop during tool check
True: NC program is stopped if breakage tolerance is exceeded
