Chapter 1: Introduction
What’s Included
The S320 is available as a single unit or two units (base/rover setup). Figure 1-1 shows the parts
included in the single unit kit and Table 1-1 lists the parts included in both kits.
Figure 1-1: S320 single unit kit
Table 1-1: S320 parts list
Item
Item
Qty
(1 Unit)
Qty
(2 Units)
Part Number
A
S320
1
2
804-0079-000 (400 MHz)
804-0090-000 (900 MHz)
B
Antenna bracket (for upward
vertical antenna mounting)
1
2
602-1096-000
C
Antenna (model/type depends on
region of use)
1
2
150-0021-000 (400 MHz)
150-0022-000 (900 MHz)
D
SD card
1
2
750-1099-000
E
Batteries (rechargeable
lithium-ion)
2
4
427-0043-000
F
Power cable, external, 2-pin circular,
3 m (for base station unit)
N/A
1
054-0119-000
G
Battery charger
1
2
427-0044-000
H
Data cable, 9-pin to 9-pin serial,
USB connector, and USB receptacle
1
2
051-0258-000
Not
shown
Pelican case
1
1
002-0083-000
Not
shown
S320 User Guide (this
document)
1
1
875-0281-000
