51
Removal
•
Support the vehicle securely on the main
stand and raise the rear wheel off the
ground.
(c) Rear wheel
(10) Lug (11) Slot
10
11
(8) Axle nut (9) Axle (10) Collar
8
9
10
Brake stopper arm nut torque:
•
Adjust the rear brake free play (page 47)
and drive chain slackness (page 42).
Installation
•
Reverse the removal procedure
Axle nut torque: 5.4 kgf-m.
2.2 kgf-m
•
After installing the wheel, apply the brake
several times and check for free wheel
rotation when released.
5 2
7 4
(1) Rear brake adjusting nut (2) Brake rod
(3) Brake arm (4) Brake stopper arm
(5) Brake panel (6) Split pin (7) Lock nut
1
3
6
•
Remove the rear axle nut (8).
•
Pull out the axle (9) and collar (10).
brake arm (3) by pushing down the brake
pedal. Disconnect the brake stopper arm
(4) from the brake panel (5) by removing
split pin (6) and lock nut (7).
•
Remove the wheel.
CAUTION
!!
Always replace used split pins with new ones.
•
Remove the rear brake adjusting nut (1)
and disconnect the brake rod (2) from the
To Next Page
