HIAB EFFER 35 - The Operating System; Components of the Operating System; Description of the Operating System

4. The Operating system
4.1. Components of the operating system
0
600
400
500
100
200
300
(1) Main control valve (3) Warning lamp
[option] for remote
controlled cranes.
(2) SCANRECO
controller [option]
(4) Pressure gauge
4.2. Description of the operating system
Crane
version
Control
valve
Operating system Controller
EFFER 35 Walvoil
Two pressure gauges for overload
monitoring
SCANRECO
[option]
DANGER
Never try to repair the operating system yourself. Repairs may only be made by an
authorised service workshop!
The Operating system
40 EFFER 35
