Engage the PTO
1. Activate the parking brake and place chocks under the wheels to prevent vehicle movement.
2. Engage the PTO (Power Take Off) and bring the vehicle engine to the correct rpm.
NOTE
• Rpm too high: the oil in the hydraulic system might overheat.
• Rpm too low: during crane operation, the vehicle engine could stall.
• The maximum rpm may depend upon a governor on your PTO combination.
CAUTION
Close the driver’s cab to prevent access to unauthorised persons.
Start the operation system
Make sure that all the levers are in neutral position before you start the operating system.
Pull out all the emergency stop buttons by turning them clockwise.
Start the controller [option]
Fasten the controller to a waist belt, or shoulder-/neck strap, in the most comfortable operating
position.
1. To activate the controller, pull out the emergency stop
button by turning it clockwise.
2. Push button (1) to activate the controller
The LED (3) becomes steady when the controller is
active and LED (2) flashing green indicates a correct
radio communication between the transmitter and the
receiver.
3. Push button (1) again.
TIP
If the controller is ON, but the crane does not
operate, check that the Mode switch (1) on
the receiver is in the REMOTE position
Starting crane operation
EFFER 35 53
