Hikmicro HM-TM36-LG/D User Manual

22
Table 3-2 Definition of Each Field of Communication Data Package
Field
Digit
Description
Value
Position
（Byte）
BEGIN
1
Command Package Start
0xF0
1
SIZE
1
Length: N+4
2
Device
Address
1
Device address
0x36
3
Class
Command
Address
1
Class Command Address
4
Subclass
Command
Address
1
Subclass Command
Address
5
Read/Write
Standard
1
Read/Write Standard
Write: 0x0
Read: 0x1
6
DATA
N
Data Content
0x00 (Default)
7 to N+6
CHK
1
Verification
Device Address + Class
Command Address +
Subclass Command
Address + Read/Write
Standard + DATA
(N+7)
END
1
End Command Package
FF
(N+8)
3.4 Receiving Data Package
The format of command from the thermal module to the controller is shown in the Figure 3-2 below.
DATA1 is high byte, and DATA N is low byte.
BEGIN SIZE
Device
Address
Subclass
Command
Address
Return
Standard
DATAN ENDCHK
N+4
Class
Command
Address
DATA1
Figure 3-2 Receiving Data Package Field
The specific definition of each field of communication data package is in Table 3-3.
