Hikmicro HM-TM36-LG/D User Manual

16
8
GND
0 V
AGND
9
CVBS
Analog Video
PAL
10
GND
0 V
AGND
11
SDA
LVCMOS_1.8 V
IIC Date
12
SCL
LVCMOS_1.8 V
IIC Clock
The appearance and dimension of 45 Pin Wire to Board Connector Interface are shown in Figure 2-12.
Figure 2-12 Appearance and Dimension of 45 Pin Wire to Board Connector Interface
2.2.3 45 Pin
The FPC socket model used with 45 Pin interface is FH26W-45S-0.3SHW (60). The wire order and electrical
description of the interface are shown in Table 2-5.
Table 2-5 Electrical Interface Description of 45 Pin Wire to Board Connector
Pin
Signal
Specification
Pin
Signal
Specification
1
VDD
1.8 V
24
Y4
OLED Brightness Data
