Hikmicro HM-TM36-LG/D User Manual

2
Param. Saving
Support
Reticle
Support
Menu
Support
Performance
and Interface
Impact Strength
750 g/1 ms
Video Interface
Support BT.656 and YUV + RAW
Communication
Interface
UART
Lens Mount
M25 × 0.5 mm
M34 × 0.75 mm
System Param.
Power Supply
2.5 to 5 VDC
Power
Consumption
0.75 W
Working
Temperature and
Humidity
-40°C to 60°C, < 90% RH
Storage
Temperature and
Humidity
-45°C to 75°C, < 90% RH
Dimension (mm)
See Chapter 2. Appearance and Interface
Weight
< 22 g (without lens and lens base)
Note:
The YUV+RAW output of HM-TM36-LG/D only supports the palette.
1.2 Technical Performance of HM-TM36-LG/S
Table 1-2 Performance of HM-TM36-LG/S
Model
Parameter
HM-TM36-LG/S
Thermal Camera Module
Detector
Image Sensor
Vanadium Oxide Uncooled Focal Plane Arrays
Response
Waveband
8 to 14 μm
NETD
< 35 mk ( @25°C, F# = 1.0)
Resolution
640 × 512
