Hikmicro HM-TM36-LG/D User Manual

17
2
VDD
Logical Circuit Power Supply
25
Y3
LVCMOS_1.8 V
3
VAN
3.3 V
Pixel Array Power Supply
26
Y2
4
VAN
27
Y1
5
GND
GND
28
Y0
6
GND
29
1.8 V
Connect to 1.8 V by Default
7
GND
No Internal Connetion
Connet to GND by Default
30
Cbcr7
OLED Color Data
LVCMOS_1.8 V
8
GND
GND
31
Cbcr6
9
PCLK
Video Clock Signal
LVCMOS_1.8 V
32
Cbcr5
10
HSYNC
Horizontal Synchronization
LVCMOS_1.8 V
33
Cbcr4
11
RESET
Reset Signal
LVCMOS_1.8 V
34
Cbcr3
12
DE
Data Enable Signal
LVCMOS_1.8 V
35
Cbcr2
13
GND
GND
36
Cbcr1
14
GND
37
Cbcr0
15
GND
38
GND
GND
16
GND
39
GND
17
GND
40
GND
18
GND
41
GND
19
GND
42
GND
20
GND
43
SCL
IIC Clock
LVCMOS_1.8 V
21
Y7
OLED Brightness Data
LVCMOS_1.8 V
44
SDA
IIC Data
LVCMOS_1.8 V
22
Y6
OLED Brightness Data
LVCMOS_1.8 V
45
SERADD
I2C Address Selection
1.8 V
LVCMOS_1.8 V
23
Y5
