Figure 3-6 Complete the Installaon
Note
• Blue Star: Side Opening. If you need to route the cable though the
boom of the panel,
remove the sheet of the side opening.
• Red Star: TAMPER Screw. It is compulsory to secure the TAMPER screw.
• No adjustments are required.
• For use within the supervised premises only.
AX Security Control Panel
14
