User Manual of Network Fisheye Camera
47
and you can see the indicator near the button start flashing, which means the WPS
function of the router is enabled. For detailed operation, please see the user guide
of the router.
4. Push the WPS button to enable the function on the camera.
Note: If there is not a WPS button on the camera, you can also click the virtual
button to enable the PBC function on the web interface.
5. Click Connect button.
When the PBC mode is both enabled in the router and the camera, the camera and the
wireless network is connected automatically.
PIN Mode
The PIN mode requires a Personal Identification Number (PIN) to be read from either
a sticker or the display on the new wireless device. This PIN must then be entered to
connect the network, usually the Access Point of the network.
Steps:
1. Choose a wireless connection on the list and the SSID is shown.
Figure 5-26 Wi-Fi Settings – WPS PIN Mode
2. Choose Use route PIN code.
