User Manual of Network Fisheye Camera
75
Pre-record: The time you set to start recording before the scheduled time or the
event. For example, if an alarm triggers recording at 10:00, and the pre-record
time is set as 5 seconds, the camera starts to record at 9:59:55.
The Pre-record time can be configured as No Pre-record, 5 s, 10 s, 15 s, 20 s, 25 s,
30 s or not limited.
Post-record: The time you set to stop recording after the scheduled time or the
event. For example, if an alarm triggered recording ends at 11:00, and the
post-record time is set as 5 seconds, the camera records until 11:00:05.
The Post-record time can be configured as 5 s, 10 s, 30 s, 1 min, 2 min, 5 min or
10 min.
Overwrite: Select Yes, and then the record files will be overwritten when the SD
card or network disk becomes full; Select No, and then the recording will stop
when the SD card or network disk becomes full.
Recording Stream: Set the stream type for recording. Main Stream and Sub
Stream are selectable.
4. Click Edit to edit the record schedule.
Figure 6-7 Record Schedule
5. Choose the day to set the record schedule.
(1) Set all-day record or segment record:
If you want to configure the all-day recording, please check the All Day
checkbox.
