HIKVISION DS-7216HGHI-K1 User Manual

Network Video Recorder User Manual
174
Configure Email
Purpose
The system can send an Email to designated users when a specified event occurs, such as an alarm
or motion event is detected, or the administrator password is changed, etc.
Before You Start
The device must be connected to a local area network (LAN) that contains an SMTP mail server.
The network must be connected to either an intranet or the Internet depending on the location of
the e-mail accounts to send notification.
Go to System > Network > Advanced > Email.
Email Settings
Configure the following Email settings.
 Enable Server Authentication: Check to enable the function if the SMTP server requires user
authentication and enter user name and password accordingly.
 SMTP Server: The IP address of SMTP Server or host name (e.g., smtp.263xmail.com).
 SMTP Port: The SMTP port. The default TCP/IP port used for SMTP is 25.
 Enable SSL/TLS: Check to enable SSL/TLS if required by the SMTP server.
 Sender: The name of the sender.
 Sender's Address: Sender's Address.
 Select Receivers: Select the receiver. Up to 3 receivers can be configured.

HIKVISION DS-7216HGHI-K1 Specifications

General

Product color	Black
Channels quantity	16 channels
Video compression formats	H.264, H.264+, H.265, H.265 Pro+, H.265+
Analog signal format system	NTSC, PAL
DC voltage	12 V
Power consumption (typical)	10 W
Operating temperature (T-T)	-10 - 55 °C
Operating relative humidity (H-H)	10 - 90 %
BNC input ports	16
USB 2.0 ports quantity	2
Ethernet LAN	Yes
Number of users	128 user(s)
Ethernet interface type	Fast Ethernet
Supported network protocols	TCP/IP, PPPoE, DHCP, Hik-Connect, DNS, DDNS, NTP, SADP, NFS, iSCSI, UPnP, HTTPS, ONVIF
HDD interface	SATA, SATA II, SATA III
Maximum HDD capacity	10000 GB

Weight and Dimensions

Depth	222 mm
Width	260 mm
Height	45 mm
Weight	1100 g
