HIKVISION DS-7600NI-E1/A User Manual

User Manual of All-in-One Network Video Recorder
183
17.1 Specifications
Model
DS-7600NI-E1/A
Video/Audio
input
IP video input
8-ch
Video compression
H.264/MPEG4
HDMI input
1-ch for HDMI video and audio input.
VGA input
1-ch for VGA video input.
VGA audio input
1 MIC interface connector for VGA audio input.
Video/Audio
output
Recording resolution
6MP/5MP/3MP/1080P/UXGA/720P/VGA/4CIF/DCIF/2CIF/CIF/QCIF
Frame rate
Main stream: 50 fps (P) / 60 fps (N)
Sub-stream: 50 fps (P) / 60 fps (N)
VGA video output
1-ch for NVR to output VGA signal.
LCD video output
22-inch displayer for NVR, HDMI and VGA input. The default input is
NVR.
Audio output
1 RCA interface connector (Linear, 1KΩ), 1 MIC interface connector and
two loudspeakers.
Network
Incoming bandwidth
80Mbps
Outgoing bandwidth
80Mbps
Remote connection
128-ch
Decoding
Playback resolution
6MP/5MP/3MP/1080P/UXGA/720P/VGA/4CIF/DCIF/2CIF/CIF/QCIF
Synchronization
Playback
8-ch@720P
Hard disk
SATA
One for an installed 2.5-inch HDD.
Capacity
500 GB and 1 TB are selectable.
External
interface
Network interface
1 RJ-45 10 /100 /1000 Mbps self-adaptive Ethernet interfaces
USB interface
2 × USB 2.0
General
Power supply
12 VAC
Consumption
≤ 36 W
Working
temperature
0 ºC ~ +50 ºC (32ºF ~ 122ºF)
Working humidity
10 % ~ 90 %
Dimensions (W × H)
(without the pedestal)
510 × 318mm (20.1"×12.5")
Dimensions (W × H)
(with the pedestal)
510 × 385mm (20.1"×15.2")
Weight
(with the bracket and
pedestal)
≤ 4 kg (8.8 lb)
