HIKVISION DS-7604NI-K1/4P User Manual

Network Video Recorder User Manual
30
Table 1-5 IR Remote Functions
No.
Name
Function Description
1
POWER
ON/OFF
• To Turn Power On:
- If User Has Not Changed the Default NVR Device ID# (255):
1. Press Power On/Off button (1).
- If User Has Changed the NVR Device ID#:
1. Press DEV button.
2. Press Number buttons to enter user-defined Device ID#.
3. Press Enter button.
4. Press Power button to start device.
• To Turn NVR Off:
- If User Is Logged On:
1. Hold Power On/Off button (1) down for five seconds to
display the “Yes/No” verification prompt.
2. Use Up/Down Arrow buttons (12) to highlight desired
selection.
3. Press Enter button (12) to accept selection.
- If User Is Not Logged On:
1. Hold Power On/Off button (1) down for five seconds to
display the user name/password prompt.
2. Press the Enter button (12) to display the on-screen keyboard.
3. Input the user name.
4. Press the Enter button (12) to accept input and dismiss the
on-screen keyboard.
5. Use the Down Arrow button (12) to move to the “Password”
field.
6. Input password (use on-screen keyboard or numeric buttons
(3) for numbers).
7. Press the Enter button (12) to accept input and dismiss the
on-screen keyboard.
8. Press the OK button on the screen to accept input and display
the Yes/No” verification prompt (use Up/Down Arrow buttons
(12) to move between fields)
9. Press Enter button (12) to accept selection.

HIKVISION DS-7604NI-K1/4P Specifications

General

Maximum resolution	3840 x 2160 pixels
Video input channels	4 channels
Supported resolutions	4K(3840 x 2160)/60Hz, 4K(3840 x 2160)/30Hz, 1920 x 1080P/60Hz, 1600 x 1200/60Hz, 1280 x 1024/60Hz, 1280 x 720/60Hz, 1024 x 768/60Hz
Product color	Black
Rack mounting	No
LED indicators	Yes
Audio RCA inputs	1
USB 2.0 ports quantity	2
Ethernet LAN data rates	10, 100 Mbit/s
Copper ethernet cabling technology	10BASE-T, 100BASE-TX
Power over Ethernet (PoE) ports quantity	4
HDD capacity	- GB
HDD interface	Serial ATA
Maximum storage capacity	6 TB
Number of HDDs installed	-
Output voltage	48 V
Power consumption (max)	10 W
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Depth	240 mm
Width	315 mm
Height	48 mm
Weight	1000 g
