Network Video Recorder User Manual
201
A Network Time Protocol (NTP) Server can be configured on your NVR to ensure the accuracy of
system date/time.
Step 1 Enter the Network Settings interface.
Menu >Configuration> Network
Step 2 Select the NTP tab to enter the NTP Settings interface, as shown in Figure 12-8.
Figure 12-8 NTP Settings Interface
Step 3 Check the Enable NTP checkbox to enable this feature.
Step 4 Configure the following NTP settings:
Interval: Time interval between the two synchronizing actions with NTP server. The unit is
minute.
NTP Server: IP address of NTP server.
NTP Port: Port of NTP server.
Step 5 Click the Apply button to save and exit the interface.
The time synchronization interval can be set from1 to 10080min, and the default value is 60min. If
the NVR is connected to a public network, you should use a NTP server that has a time
synchronization function, such as the server at the National Time Center (IP Address:
210.72.145.44). If the NVR is setup in a more customized network, NTP software can be used to
establish a NTP server used for time synchronization.
12.2.4 Configuring SNMP
Purpose:
You can use SNMP protocol to get device status and parameters related information.
Step 1 Enter the Network Settings interface.
Menu >Configuration> Network
Step 2 Select the SNMP tab to enter the SNMP Settings interface, as shown in Figure 12-9.

Table of Contents

Other manuals for HIKVISION DS-7716NI-K4/16P

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the HIKVISION DS-7716NI-K4/16P and is the answer not in the manual?

HIKVISION DS-7716NI-K4/16P Specifications

General IconGeneral
Input bandwidth160 Mbit/s
Maximum resolution4096 x 2160 pixels
Alarm input channels16
Video input channels16 channels
Alarm output channels4
Supported resolutions4096 x 2160, 3840 x 2160, 2560 x 1440, 1920 x 1080, 1600 x 1200, 1280 x 1024, 1280 x 720
Audio formats supportedG.711 A-law, G.711 μ-law, G.726
Video formats supportedH.264, H.264+, H.265, H.265+, MPEG4
HDD capacity- GB
HDD interfaceSATA
Maximum storage capacity8 TB
Number of HDDs installed0
Networking standardsIEEE 802.3af, IEEE 802.3at
USB 2.0 ports quantity2
Ethernet LAN data rates10, 100, 1000 Mbit/s
Power over Ethernet (PoE)Yes
Ethernet LAN (RJ-45) ports1
Supported network protocolsTCP/IP, DHCP, IPv4, IPv6, DNS, DDNS, NTP, RTSP, SADP, SMTP, SNMP, NFS, iSCSI, ISUP, UPnP, HTTP, HTTPS
AC input voltage100 - 240 V
AC input frequency50 - 60 Hz
Power consumption (typical)20 W
Total Power over Ethernet (PoE) budget200 W
Operating temperature (T-T)-10 - 55 °C
Operating relative humidity (H-H)10 - 90 %
CertificationFCC Part 15 Subpart B, ANSI C63.4-2014 CE EN 55032: 2015, EN 61000-3-2, EN 61000-3-3, EN 50130-4, EN 55035: 2017
Product colorBlack
Wi-FiNo
Weight and Dimensions IconWeight and Dimensions
Depth400 mm
Width445 mm
Height75 mm
Weight5000 g
