Network Video Recorder User Manual
142
7.1.3 Backing up by Event Search
Purpose:
Back up event-related record files using USB devices (USB flash drives, USB HDDs, USB writer),
SATA writer or eSATA HDD. Quick Backup and Normal Backup are supported.
Step 1 Enter Export interface.
Menu>Export>Event
Step 2 Select the cameras to search.
Step 3 Select the event type to alarm input, motion, VCA or POS.
Figure 7-9 Event Search for Backup
The POS event type is supported by the DS-7600/7700/8600/9600-I (/P) series NVR only.
Step 4 Set the search conditions and click Search button to enter the search result interface. For the
POS event type, you can also set the Keyword and enable the Case Sensitivity (upper case
and lower case) to search the video files with the key word contained POS information.
Step 5 The matched video files are displayed in Chart or List display mode. Select video files from
the Chart or List interface to export.

Table of Contents

Other manuals for HIKVISION DS-7732NI-I4

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the HIKVISION DS-7732NI-I4 and is the answer not in the manual?

HIKVISION DS-7732NI-I4 Specifications

General IconGeneral
Playback modesPause, Play
Maximum resolution3840 x 2160 pixels
Alarm input channels16
Video input channels32 channels
Alarm output channels4
Video formats supportedH.264, H.265, MPEG4
Resolution at capture speed1920x1080@60fps, 3840x2160@30fps
On/off switchYes
Product colorBlack, Silver
Rack capacity1.5U
Operating temperature (T-T)-10 - 55 °C
Operating relative humidity (H-H)10 - 90 %
AC input voltage100 - 240 V
Power consumption (typical)20 W
RS-485 ports1
USB 2.0 ports quantity2
Ethernet LAN data rates10, 100 Mbit/s
HDD capacity- GB
HDD interfaceSerial ATA
Maximum storage capacity24 TB
Number of HDDs installed-
Total installed storage capacity12000 GB
Weight and Dimensions IconWeight and Dimensions
Depth390 mm
Width445 mm
Height70 mm
