HIKVISION DS-7732NI-I4 User Manual

Network Video Recorder User Manual
170
9.3 Configuring POS Privacy Information Filtering
Purpose:
You can set the POS privacy information to not display on the image.
Step 1 Enter the POS settings interface.
Menu > Configuration > POS> POS Settings
Step 2 Click the button of the Privacy Settings to enter the POS privacy information filtering
settings interface.
Figure 9-14 POS Privacy information filtering settings
Step 3 Edit three information text (1 to 32 characters) types in the field.
Step 4 Click OK to save the settings. The defined privacy information will be displayed in ***on the
image instead.
9.4 Configuring POS Alarm
Purpose:
Set the POS alarm parameters to trigger certain channels to start recording, or trigger full screen
monitoring, audio warning, notifying the surveillance center, sending email and so on.
Step 1 Enter the POS settings interface.
Menu > Configuration > POS> POS Settings
Step 2 Follow the steps in Chapter 9.1-9.2 to configure the POS settings.
Step 3 Click to enter the alarm settings interface.

HIKVISION DS-7732NI-I4 Specifications

General

Playback modes	Pause, Play
Maximum resolution	3840 x 2160 pixels
Alarm input channels	16
Video input channels	32 channels
Alarm output channels	4
Video formats supported	H.264, H.265, MPEG4
Resolution at capture speed	1920x1080@60fps, 3840x2160@30fps
On/off switch	Yes
Product color	Black, Silver
Rack capacity	1.5U
Operating temperature (T-T)	-10 - 55 °C
Operating relative humidity (H-H)	10 - 90 %
AC input voltage	100 - 240 V
Power consumption (typical)	20 W
RS-485 ports	1
USB 2.0 ports quantity	2
Ethernet LAN data rates	10, 100 Mbit/s
HDD capacity	- GB
HDD interface	Serial ATA
Maximum storage capacity	24 TB
Number of HDDs installed	-
Total installed storage capacity	12000 GB

Weight and Dimensions

Depth	390 mm
Width	445 mm
Height	70 mm
