Network Video Recorder User Manual
144
7.2 Managing Backup Devices
Management of USB flash drives, USB HDDs and eSATA HDDs
Step 1 Enter the Export interface.
Figure 7-12 Storage Device Management
Step 2 Backup device management.
Click New Folder button if you want to create a new folder in the backup device.
Select a record file or folder in the backup device and click button if you want to delete
it.
Click Erase button if you want to erase the files from a re-writable CD/DVD.
Click Format button to format the backup device.
If the inserted storage device is not recognized:
Click the Refresh button.
Reconnect device.
Check for compatibility from vendor.

Table of Contents

Other manuals for HIKVISION DS-7732NI-I4

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the HIKVISION DS-7732NI-I4 and is the answer not in the manual?

HIKVISION DS-7732NI-I4 Specifications

General IconGeneral
Playback modesPause, Play
Maximum resolution3840 x 2160 pixels
Alarm input channels16
Video input channels32 channels
Alarm output channels4
Video formats supportedH.264, H.265, MPEG4
Resolution at capture speed1920x1080@60fps, 3840x2160@30fps
On/off switchYes
Product colorBlack, Silver
Rack capacity1.5U
Operating temperature (T-T)-10 - 55 °C
Operating relative humidity (H-H)10 - 90 %
AC input voltage100 - 240 V
Power consumption (typical)20 W
RS-485 ports1
USB 2.0 ports quantity2
Ethernet LAN data rates10, 100 Mbit/s
HDD capacity- GB
HDD interfaceSerial ATA
Maximum storage capacity24 TB
Number of HDDs installed-
Total installed storage capacity12000 GB
Weight and Dimensions IconWeight and Dimensions
Depth390 mm
Width445 mm
Height70 mm
