HIKVISION DS-C30S-S23 User Manual

Video Wall Controller • User Manual
4
Activate the Device via SADP Software
Activate the Device via Web Browser
Use a network cable to connect a computer to the device.
Set an IP address for the computer.
The IP address of the computer ranges from 192.0.0.2 to 192.0.0.253 (excluding 192.0.0.64).
By default, the device IP address is 192.0.0.64.
Enter 192.0.0.64 in the computer browser to enter the device activation page.
Set the activation password.
Click Activate.

HIKVISION DS-C30S-S23 Specifications

General

Product color	Black
Rack capacity	8U
Built-in display	Yes
Housing material	Metal
Input voltage	100 - 240 V
Input frequency	50/60 Hz
Power consumption (max)	1000 W
Ethernet LAN data rates	10, 100, 1000 Mbit/s
RJ-45 ports quantity	2
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Depth	447 mm
Width	442 mm
Height	354.8 mm
