HIKVISION DS-C30S-S23 User Manual

Video Wall Controller • User Manual
45
Set Device Exception Alarm
Maintain the System
Go to Maintenance and Security → System Maintenance to configure the following parameters:
 Click Restart to restart the device.
 Click to select an upgrade file, and click Upgrade. You need to get the upgrade file in
advance and save it locally.
Upgrade the System
 Backup the device parameters.

HIKVISION DS-C30S-S23 Specifications

General

Product color	Black
Rack capacity	8U
Built-in display	Yes
Housing material	Metal
Input voltage	100 - 240 V
Input frequency	50/60 Hz
Power consumption (max)	1000 W
Ethernet LAN data rates	10, 100, 1000 Mbit/s
RJ-45 ports quantity	2
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Depth	447 mm
Width	442 mm
Height	354.8 mm
