HIKVISION DS-C30S-S23 User Manual

Video Wall Controller • User Manual
18
If the light board data is missing, you can import the correction file to batch correct screens or
seams. Correction file should be in VU3 format, and the file size should be no more than 1 GB.
1) Switch on Enable to start the correction configuration.
2) Click to select an area as the start point of batch correction.
3) Select File Correction.
4) Click , select a VU3 file, and click Import.
File Correction
Add a Network Signal Source via IP Address
Go to Video Wall Operation → Signal Source, click , and select IP Address.
Enter the signal source information and stream media information.
 Select an added group or click Add Group to create a new group.
 Select the channel type. You can select Conventional Network Source or Zero-Channel
Network Source.

HIKVISION DS-C30S-S23 Specifications

General

Product color	Black
Rack capacity	8U
Built-in display	Yes
Housing material	Metal
Input voltage	100 - 240 V
Input frequency	50/60 Hz
Power consumption (max)	1000 W
Ethernet LAN data rates	10, 100, 1000 Mbit/s
RJ-45 ports quantity	2
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Depth	447 mm
Width	442 mm
Height	354.8 mm
