HIKVISION DS-C30S-S23 User Manual

Video Wall Controller • User Manual
19

If you select Conventional Network Source, enter Number of Channels according to the
channel quantity of the network signal source, and select the channel to add.

If you want to add a Network Video Recorder (NVR), the number of channels should start from
33. The first 32 channels are reserved. For example, if you want to add a 32-channel NVR, the
number of channels should be 64.
 Click More to select the transmission protocol, stream type, device manufacturer, and
streaming media information.
After enabling Get Stream via Streaming Server, you can perform live view data forwarding
through the streaming server to reduce network stress.

HIKVISION DS-C30S-S23 Specifications

General

Product color	Black
Rack capacity	8U
Built-in display	Yes
Housing material	Metal
Input voltage	100 - 240 V
Input frequency	50/60 Hz
Power consumption (max)	1000 W
Ethernet LAN data rates	10, 100, 1000 Mbit/s
RJ-45 ports quantity	2
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Depth	447 mm
Width	442 mm
Height	354.8 mm
