HIKVISION DS-C30S-S23 User Manual

Video Wall Controller • User Manual
7
Configure the Device IPv4 Address
Select the NIC type.
Set the IPv4 address, IPv4 subnet mask, and IPv4 gateway.
Click Save.
Remove the network cable that connects the device and computer, and use the network
cable to connect the device to the on-site network. Enter the configured device IP address in
the web browser of the computer to log in to the web page of the device.
Configure a Video Wall
Go to Video Wall Configuration, select a video wall in the upper left corner and click Edit
Video Wall Specification.

HIKVISION DS-C30S-S23 Specifications

General

Product color	Black
Rack capacity	8U
Built-in display	Yes
Housing material	Metal
Input voltage	100 - 240 V
Input frequency	50/60 Hz
Power consumption (max)	1000 W
Ethernet LAN data rates	10, 100, 1000 Mbit/s
RJ-45 ports quantity	2
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Depth	447 mm
Width	442 mm
Height	354.8 mm
