HIKVISION DS-C30S-S23 User Manual

Video Wall Controller • User Manual
6
Chapter 3 Device Configuration
On the web page, you can configure video walls, operate video walls, configure the device
parameters, and maintain system and device security.
Log In to the Device via Web Browser
Enter the device factory IP address in the web browser of the computer.
Enter the user name and the set activation password.
Login Page
Click Log In.
Configure the Network Address
Go to Configuration → Network → Network Configuration → TCP/IP.

HIKVISION DS-C30S-S23 Specifications

General

Product color	Black
Rack capacity	8U
Built-in display	Yes
Housing material	Metal
Input voltage	100 - 240 V
Input frequency	50/60 Hz
Power consumption (max)	1000 W
Ethernet LAN data rates	10, 100, 1000 Mbit/s
RJ-45 ports quantity	2
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Depth	447 mm
Width	442 mm
Height	354.8 mm
