HIKVISION DS-C30S-S23 User Manual

Video Wall Controller • User Manual
3
Chapter 2 Device Activation
First activate the device before using the device for the first time. When activating the device, obey
the following requirements to set the password:
 To improve system security, it is highly recommended to change password regularly. In order
to protect your privacy and corporate data and avoid network security issues, it is
recommended to set strong password that meets security requirements.
 Password should contain 8 to 16 characters and at least 2 of the following types: digits,
lowercase letters, uppercase letters, and special characters.
 Password cannot contain user name, 123, admin, 4 or more continuously ascending or
descending digits, or 4 or more consecutive repeated characters.
Activate the Device via SADP Software
Download the SADP software from the Hikvision website and install the SADP software.
Open the SADP software.
Select the device that is not activated.

When the computer is in the same network segment with the device, you can search the
device using the SADP software in the computer.

If the device cannot be searched through SADP, you can close the SADP software and restart
the SADP software.
Enter the password and confirm it in the right corner.
Click Activate.

HIKVISION DS-C30S-S23 Specifications

General

Product color	Black
Rack capacity	8U
Built-in display	Yes
Housing material	Metal
Input voltage	100 - 240 V
Input frequency	50/60 Hz
Power consumption (max)	1000 W
Ethernet LAN data rates	10, 100, 1000 Mbit/s
RJ-45 ports quantity	2
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Depth	447 mm
Width	442 mm
Height	354.8 mm
