HIKVISION DS-C30S-S23 User Manual

Video Wall Controller • User Manual
31
Only some models support screen maintenance. Please refer to the actual capability of the device.
Go to Configuration → System → Serial Port Settings → Mater Device Serial Port Settings,
select Screen Control as the working mode, set the baud rate of the device same as the baud
rate of the screen, and set other serial port parameters.
Configure Serial Port
The serial port also supports the keyboard control working mode. If you need to use the serial port
for keyboard control, select Keyboard Control as the working mode, and set the baud rate of the
device same as the baud rate of the keyboard.
Connect the screen with the device by using the serial port.
Go to Screen Maintenance and select an output.

HIKVISION DS-C30S-S23 Specifications

General

Product color	Black
Rack capacity	8U
Built-in display	Yes
Housing material	Metal
Input voltage	100 - 240 V
Input frequency	50/60 Hz
Power consumption (max)	1000 W
Ethernet LAN data rates	10, 100, 1000 Mbit/s
RJ-45 ports quantity	2
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Depth	447 mm
Width	442 mm
Height	354.8 mm
