Actuators Parameters
Parameter Default Min ÷ Max Description
Actuator - Brushes
Timeout # sec.
10 0 ÷ 30 Max working time of the brushdeck Actuator.
Actuator - Brushes
Overload Level # Amp.
5.0 2.0 ÷ 10.0 Brushdeck Actuator Rated current; with T Nom manages the
amperometric protection (alarm + stop Actuator).
Actuator - Brushes
Overload Time # sec.
2.0 0.1 ÷ 5.0 Brushdeck Actuator Rated Timer; with I Nom manages the
amperometric protection (alarm + stop Actuator).
Actuator - Squeegee
Timeout # sec.
5 0 ÷ 30 Max working time of the Squeegee Actuator.
Actuator - Squeegee
Overload Level # Amp.
5.0 2.0 ÷ 10.0 Squeegee Actuator Rated current; with T Nom manages the
amperometric protection (alarm + stop Actuator).
Actuator - Squeegee
Overload Time # sec.
2.0 0.1 ÷ 5.0 Squeegee Actuator Rated Timer; with I Nom manages the am-
perometric protection (alarm + stop Actuator).
Actuator - Squeegee
Traction reverse Delay # sec.
1.0 0.0 ÷ 10.0 With reverse gear, Time after which the Actuator lifts the
Squeegee.
Traction Parameters
Parameter Default Min ÷ Max Description
Traction - Speed Sets
Acceleration Ramp 1 - # sec.
3.0 0.5 ÷ 5.0 In Transfer Mode, Time to reach the max speed.
Traction - Speed Sets
Deceleration Ramp 1 - # sec.
2.0 0.3 ÷ 5.0 When the traction lever is released, the time necessary to stop
the machine.
Traction - Speed Sets
Reverse Ramp 1 - # sec.
2.0 0.3 ÷ 5.0 In Transfer Mode, Time to pass from forward way to reverse
way and viceversa.
Traction - Speed Sets
Forward Max Speed # %
100 50 ÷ 100 Maximum speed in forward way (in % of the max reachable
speed).
Traction - Speed Sets
Backward Max Speed # %
50 10 ÷ 100 Maximum speed in reverse way (in % of the forward way set
speed).
Traction - Speed Sets
Minimum Speed # %
0 0 ÷ 50 Speed at the minimum pressure of the traction lever.
Traction - Speed Sets
Mode2 Speed # %
70 10 ÷ 100 In Working Mode, Maximum speed in forward way (in % of the
max reachable speed).
Traction - Speed Sets
Speed level #1 %
50 0 ÷ 100 Max forward speed, Level 1.
Traction - Speed Sets
Speed level #2 %
75 0 ÷ 100 Max forward speed, Level 2.
Traction - Speed Sets
Speed level #3 %
100 0 ÷ 100 Max forward speed, Level 3.
Traction - Speed Ref
Signal Min Position # V
0.7 0.0 ÷ 10.0 Minimum voltage of the released potentiometer.
Traction - Speed Ref
Signal Max Position # V
3.3 0.0 ÷ 15.0 Max voltage of the active potentiometer.
Traction - Speed Ref
Signal Dead Band # mV
50 0 ÷ 500 Potentiometer dead band
